APC Smart-UPS On-Line 6kVA/6kW Tower 230V SRT6KXLI

APC Smart-UPS On-Line 6kVA/6kW Tower 230V SRT6KXLI

1,00 EGP

APC Smart-UPS On-Line 6kVA/6kW Tower 230V

This 6000VA/6000W On-line pure sine wave UPS provides scalable runtime while minimizing maintenance.

  • APC Smart-UPS On-Line
  • 6kVA/6kW
  • Tower
  • 230V
  • 6x C13+4x C19 IEC outlets
  • Network Card+SmartSlot
  • W/O rail kit

Description

APC Smart-UPS On-Line 6kVA/6kW Tower, 230V SRT6KXLI

This product is part of the Smart-UPS On-Line range that provides high-density, true double-conversion on-line power protection. This APC Smart-UPS On-Line 6kVA/6kW Tower, 230V SRT6KXLI 6000VA/6000W On-line pure sine wave UPS provides scalable runtime while minimizing maintenance. The 4U rack/tower convertible SRT has an Embedded Network Management Card for network-based UPS monitoring and management. The UPS has an additional SmartSlot for connectivity and PowerChute Network Shutdown support for graceful unattended shutdown. It comes with hard wire 3-wire input, 6x IEC 60320 C13 and 4x IEC 60320 C19 outlets, and 2x IEC jumper cables. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. Its dimensions are 719mm (depth) x 432mm (height) x 174mm (width) and weighs 60.00kg. Ideal for servers, voice/data networks, medical labs, and light industrial applications. It conforms to CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, and VDE. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Main
Run time for load

W

information_stroke
Min-max: 600-6000 W
2min 28s
Max. Capacity Used
information_stroke

100 %

Main Input Voltage 230 V
Other Input Voltage 220 V
240 V
Main Output Voltage 230 V
Other Output Voltage 220 V
240 V
rated power in W 6000 W
rated power in VA 6000 VA
nb of power socket outlets 6 IEC 60320 C13
2 IEC Jumpers
4 IEC 60320 C19
output connector type Hard wire 3-wire (H N + E) 1
battery type Lead-acid battery
provided equipment CD with software
Documentation CD
Installation guide
Removable support feet
Temperature probe
USB cable
Warranty card
Web/SNMP management card
General
product web sub-family High density
Number of power module free slots 0
Number of power module filled slots 0
redundant No
Physical
colour Black
height 43.2 cm
width 17.4 cm
depth 71.94 cm
net weight 60 kg
mounting preference No preference
mounting mode Rack-mounted with kit
two post mountable 0
USB compatible Yes
mounting position Vertical
Input
network frequency 40…70 Hz auto-sensing
number of input connectors 1 hard wire 3-wire (1P + N + E)
input voltage limits 100…275 V adjustable (half load)
Output
Maximum configurable power in W 6000 W
harmonic distortion Less than 2 %
output frequency 50/60 Hz +/- 3 Hz sync to mains
crest factor 3 : 1
UPS type Double conversion online
Wave type Sine wave
bypass type Internal bypass (automatic and manual)
Maximum configurable power in VA 6000 VA
Conformance
product certifications CE
EAC
IRAM
RCM
VDE
marking CE Mark
Environmental
ambient air temperature for operation 0…40 °C
relative humidity 0…95 % non-condensing
operating altitude 0…10000 ft
ambient air temperature for storage -15…45 °C
storage Relative Humidity 0…95 % Non-condensing
storage altitude 0.00…15240.00 m
acoustic level 55 dBA
heat dissipation 1300 Btu/h
IP degree of protection IP20
Batteries & Runtime
Run Time View Runtime Graph

action_new_window
Efficiency View Efficiency Graph

action_new_window
number of battery filled slots 0
Battery recharge time 1.5 h
number of battery replacement quantity 1
battery voltage 192 V
battery charger power 597 W rated
Battery power in VAH 902 VAh runtime
battery life 3…5 year(s)
Replacement battery APCRBC140

action_new_window
battery option SRT192BP 1 2706 VAh
SRT192BP 2 4510 VAh
SRT192BP 3 6314 VAh
SRT192BP 4 8118 VAh
SRT192BP 5 9922 VAh
SRT192BP 6 11726 VAh
SRT192BP 8 15334 VAh
SRT192BP 10 18942 VAh
extended runtime 1
Communications & Management
free slots 1
control panel Multifunction LCD status and control console
alarm Audible and visible alarms prioritized by severity
Emergency power off Yes
Surge Protection and Filtering
Surge energy rate 480 J
Packing Units
Package 1 Weight 67 kg
Package 1 Height 37 cm
Package 1 Width 61 cm
Package 1 Length 96 cm
Number of Units in Package 3 6

SRT6KXLI Datasheet

Additional information

brand

APC
